Sunpal MPPT 60A Solar Charge Controller (12V / 24V / 36V / 48V) — High-Efficiency LiFePO₄, GEL, AGM, and Flooded Battery Charger
RM778.00
In stock
Ultra-High MPPT Efficiency ≥99.5% – Tracks the optimal power point for maximum solar energy harvest.
Whole Machine Conversion Efficiency Up to 98% – Reduces power loss and enhances system performance.
Smart Current Limiting Mode – Automatically adjusts charging power to prevent exceeding the rated charging current.
Multi-Battery Compatibility – Supports gel, sealed, flooded, and lithium batteries with an integrated temperature compensation function to extend battery lifespan.
Automatic System Voltage Detection (12V/24V/48V)
Perfect for off-grid solar systems, RVs, boats, homes, and commercial solar applications, the Sunpal MPPT 60Aensures maximum power efficiency and battery longevity.
Description
Sunpal MPPT 60A Solar Charge Controller (12V / 24V / 36V / 48V)
Key Features:
- Ultra-High MPPT Efficiency ≥99.5% – Tracks the optimal power point to harvest maximum solar energy from your panels.
- Whole Machine Conversion Efficiency Up to 98% – Minimizes energy loss and improves overall solar system performance.
- Smart Current Limiting Mode – Automatically adjusts charging power to prevent exceeding the rated 60A charging current.
- Multi-Battery Compatibility – Supports GEL, sealed, flooded, and LiFePO₄ lithium batteries with built-in temperature compensation for longer lifespan.
- Automatic System Voltage Detection (12V / 24V / 36V / 48V):
- 12V System: Max solar input 800W (Solar Vmp: 17V–75V)
- 24V System: Max solar input 1600W (Solar Vmp: 36V–75V)
- 36V System: Max solar input 2400W (Solar Vmp: 55V–120V)
- 48V System: Max solar input 3200W (Solar Vmp: 70V–120V)
- User-Friendly LCD Display & Adjustable Parameters – Monitor real-time voltage, current, and charging status with easy parameter customization.
- Modbus Communication Protocol – Enables integration with smart monitoring and remote control systems.
- Comprehensive Protection & Fault Diagnosis – Includes overcharge, over-discharge, reverse polarity, short circuit, and over-temperature protection with LED fault indicators.
Ideal for off-grid solar systems, RVs, boats, homes, and commercial solar setups, the Sunpal MPPT 60A (12V/24V/36V/48V) ensures maximum charging efficiency, extended battery life, and reliable solar performance.
Specifications:
- System Voltage: 12V / 24V / 36V / 48V Auto Detection
- No-load Loss: 0.7W–1.2W
- Battery Voltage Range: 9V–64V
- Max Solar Input Voltage: 150V (Voc)
- Rated Charging Current: 60A
- Max Conversion Efficiency: 98%
- MPPT Tracking Efficiency: ≥99.5%
- Operating Temperature: -35°C to +45°C
- Protection Level: IP32
- Net Weight: 1.4 kg
- Warranty: 1 Year
